29
1
GENERAL INFORMATION
CONOSCENZA DEL VEICOLO
E
G
F
REGOLATORE - TELERUTTORE
AVVIAMENTO - BOBINA A.T.
Per accedere al regolatore di ten-
sione E al teleruttore d’avviamento
F e alla bobina A.T. G è necessario
rimuovere il serbatoio (vedi
Smon-
taggio serbatoio carburante
pag.
49)
REGULATOR - RELAY SWITCH
STARTING SYSTEM - HV COIL
Remove the fuel tank as directed
on page 49 to gain access to volt-
age regulator E, starting relay
switch F and HV coil G.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Beta RR 125 series and is the answer not in the manual?

Beta RR 125 series Specifications

General IconGeneral
Displacement124.8 cc
Cooling SystemLiquid cooled
Compression Ratio12.5:1
Fuel SystemElectronic fuel injection
IgnitionElectronic
Transmission6-speed
Front Tire90/90-21
LubricationWet sump
ClutchWet multi-disc
Final DriveChain
Front Suspension41 mm upside-down fork
Rear SuspensionMonoshock
Front Brake260 mm disc
Rear Brake220 mm disc
