51
3
MAINTENANCE AND CHECKS
MANUTENZIONE E CONTROLLI
E
C
D
Smontaggio parafango anteriore
Rimuovere le quattro viti C situate
sotto il parafango anteriore.
Successivamente rimuovere la vite
D (posta sempre sotto il parafango)
di fissaggio del rinforzo parafango.
Rimuovere, infine, le due viti di fis-
saggio E del rinforzo parafango po-
ste sopra il rinforzo stesso.
Removing the front mudguard
Remove the four screws C from un-
der the front mudguard.
Also remove mudguard brace fix-
ing screw D from under the mud-
guard.
Finally remove the two brace fixing
screws E from the top of the brace.
