GENERAL INFORMATION
26
GB
WIRING DIAGRAM RR 2t
1) RIGHT-HAND FRONT TURN INDICATOR (12V-10W BULB)
2) FRONT BRAKE LIGHT BUTTON
3) START BUTTON
4) WHEEL REVOLUTION SENSOR
5) TRAFFICATOR LIGHTS TELL TALE LAMP
6) RIGHT BUTTON
7) DISPLAY
8) LEFT BUTTON
9) HEADLIGHT TELL TALE LAMP
10) HEADLIGHT (12V-35/35W BULB)
11) 12V HORN
12) ENGINE STOP BUTTON
13) HORN BUTTON
14) HEADLIGHT SELECTOR
15) TURN SIGNAL LAMPS SWITCH
16) LEFT-HAND CONTROL GROUP
17) LEFT-HAND FRONT TURN INDICATOR (12V-10W BULB)
18) REGOLATOR 12V
19) ELECTRIC FAN KIT (OPTION)
20) UNIT TURN SIGNAL LAMPS
21) LEFT-HAND REAR TURN INDICATOR (12V-10W BULB)
22) TAIL LIGHT WITH LED
23) RIGHT-HAND REAR TURN INDICATOR (12V-10W BULB)
24) NUMBER-PLATE LIGHT
25) BATTERY POSITIVE TERMINAL
26) BATTERY 12V - 4Ah
27) GENERATOR
28) 10A FUSE
29) FRAME EARTH WIRE
30) STARTER MOTOR
31) STARTER RELAY
32) BATTERY NEGATIVE TERMINAL
33) ELECTRONIC CONTROL UNIT
34) HT COIL
35) SPARK PLUG
36) REAR BRAKE LIGHT BUTTON
37) FRAME EARTH
38) PARKING LIGHT 12V-5W
Key to colours
Bi = White
Ve = Green
Ma = Brown
Vi = Purple
Bl = Blue
Ne = Black
Gi = Yellow
Rs = Red
Ar = Orange
Az = Sky-blue
Ro = Pink
Gr = Grey
