REMOVING AND INST
ALLING SUPERSTRUCTURES
77
GB
W
ARNING
Make sure the bayonet joint
3
i
s
firmly inser
ted into the button lock.
3
REMOVING AND
INST
ALLING AIR FIL
TER
COVER P
ANEL
Remove the saddle (page 76).
Grab the side panel in the front side and
pull out.
T
o refit insert the tabs
1
into their slots.
Slide the side panel toward the vehicle.
1
76
78
