1
GENERAL INFORMA
TION
9
GB
Get of
f the male end wrenches (8 mm) and
hexagon socket
3
. With these is possible
to unscrew the screw
4
.
Pull the left cover of rear fender and unhook
two rubber band
5
. Now the toolkit
6
is
accessible.
T
o take the tool kit, remove the saddle
1
(page 76). Pull the rear side panel
Pull the rear side panel
2
(page 77).
4
1
2
3
6
5
5
8
10
