BETAFPV Cetus FPV Kit User Manual

horizontal surface
and wait for a while
Purple
Solid
Quadcopter accessed the
OSD menu
Green
Flashing fast
Quadcopter is in binding
mode
White
Flashing fast
Arming failed, because
the throttle joystick was
not at the lowest position
when arming
Disarm, and place
the throttle joystick
at the lowest
position
Brown
Flashing slowly
Loss of remote control
radio transmitter signal
Re-establish the
connection with the
remote control
radio transmitter
Remote Control Radio Transmitter LED Light & Beep Status Codes
There is a blue & red LED indicator light around the power button which indicates the status of
the remote control radio transmitter.

BETAFPV Cetus FPV Kit Specifications

General

Flight Time	4-5 minutes
Wheelbase	75mm
VTX	25mW
Propeller	40mm 3-blade Propeller
Control Range	Up to 80 meters
Battery	1S 450mAh LiPo Battery
Charging Time	30-40 minutes
