BETAFPV Cetus FPV Kit User Manual

l Step 6: Disconnect and remove the battery from the quadcopter. A long press of the
power button on the remote control radio transmitter will turn it off after three
beeps.
First Person View (FPV)
First-person view (FPV) is the real-time transmission of the camera image to FPV goggles.
l Take out the goggles, install the headband;
l Slide the power switch to the right. The screen lights up and the VR02 goggles are
turned on;
l Long press the “S” button for 1 second to turn on the fast frequency search function.
After 3 seconds, a beep will sound and the corresponding FPV cross-machine
screen is displayed in the goggles, indicating that the frequency search is
complete.

BETAFPV Cetus FPV Kit Specifications

General

Flight Time	4-5 minutes
Wheelbase	75mm
VTX	25mW
Propeller	40mm 3-blade Propeller
Control Range	Up to 80 meters
Battery	1S 450mAh LiPo Battery
Charging Time	30-40 minutes
