normal data.
ESC *, FS q, GS /, GS v
FS q n [xL xH yL yH d1...dk]1...[xL xH yL yH d1...dk]n
FS q n [xL xH yL yH d1...dk]1...[xL xH yL yH d1...dk]n
28 113 n [xL xH yL yH d1...dk]1...[xL xH yL yH d1...dk]n
Hexadecimal: 1C 71 n m [xL xH yL yH d1...dk]1...[xL xH yL yH d1...dk]n
1≤xH≤3 (when 1≤(xL+xH×256)≤1023
1≤yL≤255
1≤yH≤1 (when 1≤(yL+yH×256)≤288
1≤d≤255
k=(xL+xH×256)×(yL+yH×256)×8
Total defined data area=192K bytes.
Define the NV bit image specified by n.
λ
n specifies the number of the defined NV bit image.
xL, xH specifies (xL+xH×256)×8 dots in the horizontal direction for
the NV bit image you are defining.
yL, yH specifies (yL+yH×256)×8 dots in the vertical direction for the
NV bit image you are defining.
λ
Frequent write command executions may damage the NV memory.
Therefore, it is recommended to write the NV memory 10 times or
less a day.
The printer performs a hardware reset after the procedure to place
the image into the NV memory. Therefore, user-defined characters,
downloaded bit images should be defined only after completing this
command. The printer clears the receiver and print buffers and
resets the mode to the mode that was in effect at power on. (this
version is not support hardware reset).
λ
This command cancels all NV bit images that have already been
defined by this command.
From the beginning of the processing of this command till the finish
of hardware reset, mechanical operations (including initializing the
position of the print head when the cover is open, paper feeding
using the FEED button, etc.) cannot be performed.
λ
During processing of this command, the printer is BUSY when writing
data to the user NV memory and stops receiving data. Therefore it is
prohibited to transmit the data, including real-time commands, during
the execution of this command.
NV bit image is a bit image defined in non-volatile memory by
and printed by FS p.
