Beurer BM 95 - ECG Stick; Display Description

43
3.2 ECG stick
1
2
3
1. Upper electrode
2. Lower electrode
3. Activation switch
3.3 Display description
4
5
6
3
2
1
7 8 9
10 11 12 13
1. Heart rate display: flashes in sync with your
heartbeat during the measurement.
2. Heart rate: shows the average heart rate during
the recording process.
3. ECG result display
4. Systolic blood pressure display
5. Diastolic blood pressure display
6. Classification of measured values
7. Standby mode = time, ECG measurement =
30sec. countdown; memory mode = shows the
number of measurements/measurement time
8. Alarm symbol
9. Low battery status symbol
10. USB connection symbol
11. Bluetooth
®
connection symbol
12. Current user memory
13. Measurement mode (blood pressure = “BP”,
ECG = “ECG”
