2. Parameter
In this menu the operation mode is adjusted.
Possibilities are: Autonomy, Override, Request-to-Talk
The current adjustment is shown in the top line. The operation mode is chosen with the left
button (4), using the right button (5) the chosen operation mode is confirmed and appears in the top
line as present operation mode.
There are three operation modes:
1. Request-to-Talk
This mode is only possible with an operator manually controlling a PC, media control system (AMX/Panja
®
, Crestron
®
). When
pressing the microphone button of the microphone unit the system registers a request-to-talk. The operator at the PC, console or
touchscreen of the media control system has control over who speaks next.
2. Autonomy
Each participant can switch on or off his microphone unit until the maximum number of open microphones (NOM) is reached.
3. Override
Each switched on microphone unit switches off the previously activated microphone unit.
3. Parameter
In this menu the button function is adjusted in the microphone units.
The current adjustment is shown in the top line.
Switching: The microphone unit is switched on and off with the microphone button.
Push-To-Talk: The microphone button acts as a Push-To-Talk button (PTT) i.e. the microphone unit
is switched on as long as the microphone button is pressed.
4. Parameter
In this menu the talk time allowed of the delegate microphone unit is adjusted.
After the talk time allowed has elapsed (in this example 120 seconds) the delegate microphone unit
switches off automatically. Use the left (4) or right (5) button to adjust the value.
