6.9 Example for Configuration “Number of Stations” (MCS 50/64 only!)
In each line up to 32 stations can be connected to the control unit.
If for example 16 stations are to be connected in line 1 and 17 stations in line 2, you must do the following:
1. MCS Editor Software
Enter the number 64 into the field “Number of Stations”. Now you have 64 stations to configure: 1 to 32 in line 1 and 33 to 64
in line 2 that is the stations 1 to 16 in line 1 and the stations 33 to 50 in line 2 (corresponds to the 17 microphone units connected
in line 2). A possible chairman station in line 2, e.g. station no. 7 corresponds to station no. 40 in the MCS Editor. Save the configuration
and download the file into the Control Unit. The control unit is now looking for 64 stations, but there are only 33 connected.
2. MCS Control Unit
Close the MCS Editor Software or disconnect the PC from the control unit.
Start the configuration with the multi-function buttons and LC-Display.
Enter the number of stations into the configuration menu (in this example 33). Refer also to chapter “5.2 Configuration”.
When the configuration is finished, the system works with 33 stations.
In the system check the control unit is looking for 33 stations and will find them.
7. Glossary
Configuration Adjustment of all parameters.
Manufacturer specific Parameters which have been set at the factory and which can be changed. Press the reset button (6)
to load these parameters.
User specific Parameters which have been set from the user. Press the reset button (4) to load these parameters.
Operation specific Adjusted parameters and their change to operate the system.
NOM Number of Open Microphones which can be switched on simultaneously.
Parameter Adjustable values, e.g. Number of the connected microphones, operation mode, input level, output
level.
PTT Push-To-Talk = adjustable operation mode for the microphone unit, where the microphone unit is
switched on as long as the microphone button of the microphone unit is pressed.
Reset All parameters are reset to the original user or manufacturer specific configuration.
System Check Automatic check of all system parameters which is carried out when the system is switched on.
