Audio
Frequency response . . . . . . . . . . . . . . . . . . . . . . . . . . 80 Hz to 19,000 Hz
T.H.D. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ≤ 1%
Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +24 V, +5 V, +15 V, -15 V
Power consumption at +24 V . . . . . . . . . . . . . . . . . . . 80 mA, 60 mA, 72 mA, 33 mA
XLR-plug
Line-output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pin 2+, 3- and 1 screen, balanced, floating, 1.55 V (+6 dBm)
Microphone Line 1 and Line 2
AF-input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 Ohm master, pin 7+, 6- and 14 screen, balanced, floating, adjustable -40 dB
AF-output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.55 V (+6 dBm), Pin 5+, 4- and 12 screen, balanced, floating, adjustable -40 dB
Power supply output . . . . . . . . . . . . . . . . . . . . . . . . . Pin 1 and 9 +24 V, 6 A
Data-Bus-line (CPU) . . . . . . . . . . . . . . . . . . . . . . . . . . Pin 2 = A, Pin 3 = B, Pin 10 = screen
acc. to RS 485 standard
Max. cable length. . . . . . . . . . . . . . . . . . . . . . . . . . . . 300 m
MCS 511 Delegate Microphone Unit
Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +24 V via microphone line
Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . max. 70 mA
AF-frequency response . . . . . . . . . . . . . . . . . . . . . . . . 80 Hz to 19,000 Hz
T.H.D. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ≤ 1%
Signal-to-noise ratio with microphone . . . . . . . . . . . ≥ 59 dB related to 1 Pa
AF-Output (+6 dBm) . . . . . . . . . . . . . . . . . . . . . . . . . . balanced, microphone line
AF-Output (-10 dBm) . . . . . . . . . . . . . . . . . . . . . . . . . unbalanced, mini-jack (3.5 mm)
Limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . compensates variations in speaking distance, cannot be switched off
Microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SHM 214 C 02 gooseneck microphone with illuminated ring, fixed
1 button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Microphone button
1 DIP-switch (No. 6) . . . . . . . . . . . . . . . . . . . . . . . . . . no function
5 DIP-switches (No. 1 to 5) . . . . . . . . . . . . . . . . . . . . . Address of the microphone units (Binary code)
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 x 3 m long cable with 15-pin Sub-D plug, microphone line
1 x 15-pin Sub-D socket, microphone line
1 x mini-jack (3.5 mm), documentation-output
Dimensions (without microphone). . . . . . . . . . . . . . . Length: 190 mm
Width: 155 mm
Height: 52 mm
Weight (without microphone) . . . . . . . . . . . . . . . . . . 1390 g
Ambient temperature . . . . . . . . . . . . . . . . . . . . . . . . 0° - 50°C
Colour. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Nextel
®
, stone grey
MCS 513 Chairman Microphone Unit
Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +24 V via microphone line
Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . max. 70 mA
AF-frequency response . . . . . . . . . . . . . . . . . . . . . . . . 80 Hz to 19,000 Hz
T.H.D. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ≤ 1%
Signal-to-noise ratio with microphone . . . . . . . . . . . ≥ 59 dB related to 1 Pa
AF-Output (+6 dBm) . . . . . . . . . . . . . . . . . . . . . . . . . . balanced, microphone line
AF-Output (-10 dBm) . . . . . . . . . . . . . . . . . . . . . . . . . unbalanced, mini-jack (3.5 mm)
Limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . compensates variations in speaking distance, cannot be switched off
Microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SHM 214 C 02 gooseneck microphone with illuminated ring, fixed
3 buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1. Priority button
2. Microphone button
3. Clear button
1 DIP-switch (No. 6) . . . . . . . . . . . . . . . . . . . . . . . . . . no function
5 DIP-switches (No. 1 to 5) . . . . . . . . . . . . . . . . . . . . . Address of the microphone units (Binary code)
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 x 3 m long cable with 15-pin Sub-D plug, microphone line
1 x 15-pin Sub-D socket, microphone line
1 x mini-jack (3.5 mm), documentation-output
Dimensions (without microphone). . . . . . . . . . . . . . . Length: 190 mm
Width: 155 mm
Height: 52 mm
