MCS 501 Delegate Microphone Unit
Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +24 V via microphone line
Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . max. 84 mA
AF-frequency response . . . . . . . . . . . . . . . . . . . . . . . . 80 Hz to 19,000 Hz
T.H.D. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ≤ 1%
Signal-to-noise ratio with microphone . . . . . . . . . . . 59 dB related to 1 Pa
AF-Output (+6 dB) . . . . . . . . . . . . . . . . . . . . . . . . . . . balanced, microphone line
Limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . compensates variations in speaking distance, cannot be switched off
Microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SHM 214 C 02 gooseneck microphone with illuminated ring, fixed
1 button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Microphone button
1 DIP-switch (No. 6) . . . . . . . . . . . . . . . . . . . . . . . . . . no function
5 DIP-switches (No. 1 to 5) . . . . . . . . . . . . . . . . . . . . . Address of the microphone units (Binary code)
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 x 3 m long cable with 15-pin Sub-D plug, microphone line, on request the
cable can be supplied individually and in special lengths,
prices and more information on request
1 x 15-pin Sub-D socket, microphone line
Dimensions (without microphone). . . . . . . . . . . . . . . Length: 170 mm
Width: 110 mm
Height: 4 mm (front panel); total: 30 mm
Weight (without microphone) . . . . . . . . . . . . . . . . . . 1090 g
Ambient temperature . . . . . . . . . . . . . . . . . . . . . . . . 0° to +50°C
Colour. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Nextel
®
, stone grey
MCS 503 Chairman Microphone Unit
Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +24 V via microphone line
Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . max. 84 mA
AF-frequency response . . . . . . . . . . . . . . . . . . . . . . . . 80 Hz to 19,000 Hz
T.H.D. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ≤ 1%
Signal-to-noise ratio with microphone . . . . . . . . . . . 59 dB related to 1 Pa
AF-Output (+6 dB) . . . . . . . . . . . . . . . . . . . . . . . . . . . balanced, microphone line
Limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . compensates variations in speaking distance, cannot be switched off
Microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SHM 214 C 02 gooseneck microphone with illuminated ring, fixed
3 buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1. Priority button
2. Microphone button
3. Clear button
1 DIP-switch (No. 6) . . . . . . . . . . . . . . . . . . . . . . . . . . no function
5 DIP-switches (No. 1 to 5) . . . . . . . . . . . . . . . . . . . . . Address of the microphone units (Binary code)
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 x 3 m long cable with 15-pin Sub-D plug, microphone line, on request the
cable can be supplied individually and in special lengths,
prices and more information on request
1 x 15-pin Sub-D socket, microphone line
Dimensions (without microphone). . . . . . . . . . . . . . . Length: 170 mm
Width: 110 mm
Height: 4 mm (front panel); total: 30 mm
Weight (without microphone) . . . . . . . . . . . . . . . . . . 1090 g
Ambient temperature . . . . . . . . . . . . . . . . . . . . . . . . 0° to +50°C
Colour. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Nextel
®
, stone grey
MCS 553 System Unit
Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +24 V via microphone line
Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . max. 74 mA
AF-frequency response . . . . . . . . . . . . . . . . . . . . . . . . 80 Hz to 19,000 Hz
T.H.D. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ≤ 1%
Signal-to-noise ratio with microphone . . . . . . . . . . . 59 dB related to 1 Pa
AF-Output (+6 dB) . . . . . . . . . . . . . . . . . . . . . . . . . . . balanced, microphone line
Limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . compensates variations in speaking distance, cannot be switched off
6 DIP-switches (No. 1 to 5) . . . . . . . . . . . . . . . . . . . . . Address of the microphone units (Binary code)
DIP-switch No. 6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . no function
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 x 3 m long cable with 15-pin Sub-D plug, microphone line, on request the
cable can be supplied individually and in special lengths,
