53
english
Noise voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 µVs
Signal-to-noise ratio related to 1 Pa . . . . . . . . . . . . . 60 dB
A-weighted equivalent SPL . . . . . . . . . . . . . . . . . . . . 26 dB
Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . unbalanced with quick-plug connection ø 7.2
Supply voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 V with drop resistance 10 kΩ
Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . 400 µA
Illuminated ring
Supply voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 V, drop resistance 3.3 kΩ
Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . 20 mA
Dimensions
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 400 mm
Head diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13.5 mm
Gooseneck diameter. . . . . . . . . . . . . . . . . . . . . . . . . . 8 mm
Gooseneck connection . . . . . . . . . . . . . . . . . . . . . . . . M 13 x 1 external thread
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174 g
Colour. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Nextel
®
, stone grey (B 2)
The gooseneck microphone is available in different lengths and versions.
Connection MCS 553 Connection MCS 553 L
ATTENTION:
For the connection of microphone units to the MCS Control Unit and for connection from microphone unit to microphone unit use
only connecting cables recommended by beyerdynamic (refer also to the chapter “Optional Accessories”).
If you use other cables make sure that you use cables with the correct wiring (refer also to the chapter “Technical Specifications”,
otherwise the microphone units and the control unit may be damaged. This will invalidate the guarantee.
Important:
The power cable and signal conducting cables must run in a sufficient distance to each other and to the microphone unit.
