Illu. No.
5
10
15
20
30
35
40
50
50
55
60
65
70
80
80
80
80
100
110
120
8000
Part No.
533.807
533.815
524.719
553.409
187.135
554.049
553530
553.425
553.417
533.904
551.872
454.478
528.862
554.413
554.421
554.448
554.456
533.777
528.862
148.105
324.264
Drawing No.
BN 55-65/A
BN 54-211/A
LPR 8602-Mini 6,4 mm
BN 56-989/A
DIN 6797-A 3,2
3 x 8 Torx
B 7-676.00-00
BN 17-642/B
BN 17-642/A
BF-66-208 Nr. 040 66 208
B 7-655.04-00
SHM 21-8/400-M13-GR
M 2,5x 6 Torx
B 24-703.01-00
B 24-703.02-00
B 24-703.03-00
B 24-703.04-00
BN 55-65/B
M 2,5x 6 Torx
SJ 5012 SW
50,00 x 20,00 AL-Matt
Description
Bottom
Shielding
Spacing piece
Rear plate
Studded disc
Oval head screw
Connecting cable
Casing (MCS 513 + MCS 523)
Casing (MCS 511 + MCS 521)
Loudspeaker (MCS 521 + MCS 523)
Connecting cable
Gooseneck microphone
Oval head screw
Base plate (MCS 511)
Base plate (MCS 513)
Base plate (MCS 521)
Base plate (MCS 523)
Bottom
Oval head screw
Elastic buffer
Sticker
