Beyerdynamic Opus 900 - S 900 Handheld Transmitters

english
55
2. S 900 Handheld Transmitter
2.1 Controls and Indicators
There are different condenser and dynamic microphone capsules for the handheld
transmitter (refer to Optional Accessories).
The S 900 C handheld transmitter has charging contacts and can be operated with the
integrated rechargeable battery pack only. Avoid a direct contact of the charging contacts to
the skin, as there is a voltage of 3 V at maximum.
S 900
S 900 C
Microphone capsule (can be unscrewed)
LC-Display
Infrared diode (at the bottom of the transmitter)
On/Off switch (at the bottom of the transmitter)
Charging contacts (at the bottom of the transmitter S 9xx C only )
S 900 M
Microphone capsule (can be unscrewed)
LC-Display
Infrared diode (on the rear)
On/Off switch
1 2
3
4
1
1
2
3
4
1
2
3
4
5
2
3
4
5
1 2
43
