Orbis – Microphone Unit
10
Opening for unlocking the gooseneck
microphone
Connection for gooseneck microphone,
5-pin XLR
Microphone button
“Clear” button to clear all delegate
microphones
Programmable function button
Orbis MU 21 Top View
Orbis MU 43/41 Bottom
Orbis MU 23 Top View
In/Out sockets to connect the microphone
unit, RJ45
Important: Do not connect Ethernet!
Phoenix connector to connect the optional
CA OL loudspeaker module
Mounting opening for installation under the
table top
