Orbis – Operation
25
Speaker
This menu is used to select the audio signal which is to be reproduced over the loudspeakers of the
microphone.
Mic:
• This setting is a mix of all the open microphones, in which the audio signals of the active speakers
can be heard over the loudspeakers of the microphone.
AUX in:
• Here the audio signal of the “Aux in” input on the Orbis CU control unit will be reproduced.
Mic + AUX in
• Both settings can be selected simultaneously so that over the loudspeakers of the microphone units
both audio signals can be heard.
Audio Out
This menu is used to select the audio signal which is to be reproduced over the audio output of the
control unit.
Mic:
• This setting is a mix of all the open microphones, in which the audio signals of the active speakers
can be heard over the loudspeakers of the microphone.
AUX in:
• Here the audio signal of the “Aux in” input on the Orbis CU control unit will be reproduced.
Mic + AUX in
• Both settings can be selected simultaneously so that over the loudspeakers of the microphone units
both audio signals can be heard.
Application example of tele conference
Audio Out: Mic
Speaker: Aux In
Application example of N-1/Mix-Minus
Audio Out: Mic
Speaker: Aux In & Mic
