Orbis – Operation
27
Error
“Error” illuminates red when an error occurs. The error in question is displayed by a white illumination.
The error display goes out when the error is corrected or when you restart.
Possible errors:
• Redundancy incorrectly chosen: e.g. “Off” when microphone units are connected in a ring
or “On” when microphone units are connected in one/two lines
• Redundancy selected correctly, interruption present
• SD card error (e.g. card full, write error)
• Real-Time-Clock (RTC) error (internal battery empty)
Lock
The settings on the control unit can be protected via a key combination or an external device. The
“Lock” function can be activated/deactivated, if there is no SD card in the slot  of the Orbis CU
control unit.
The “Lock” function is in two stages. When pressing the “REC” button the first time, the system
settings will be locked, the system volume however can still be selected. When pressing the “REC”
button another time, this parameter will be locked as well.
• Select the “Volume” menu.
• Press and hold the “REC” button .
• Press the rotary encoder  once.
• The “Lock” display will illuminate white and displays the activated status of the “Lock” function.
The following functions can still be operated: volume, record and switching off to stand-by.
• If you press the rotary encoder once again, while holding the “REC” button the other functions
such as volume, record or switching off to stand-by will also be locked.
• In order to deactivate the “Lock” function, please proceed as described above. The “Lock” display
will not illuminate any more.
• When an error occurs, it will be issued via the RS 232 interface.
