Beyerdynamic QUINTA Series - Room Combining Configuration Commands

24 System Configuration Commands
3.5 j and ~j commands (2)
configuration
This command group shows, activates and deactivates the room partitioning
with the rooms A, B, C and D as well as it configures the room stored in the MUs. So it
covers the complete management of room partitioning.
Important Note
The ~j command can be executed in broadcast as well as in unicast mode; please refer
to chapter 3.2 for details. Since it is common practice to clear only one particular MU
speak request, an application of this command structure in unicast mode is not unlikely.
Without selecting a specific MU with the M command, the system is in broadcast mode
by default and all MUs are addressed.
Communication direction
Controller -> CU
Syntax
Description
j C
Get information about active and inacti-
ve rooms (A, B, C and D); this information is listed
under the name Cell-ID
j C 2 v
Activate or deactivate rooms A, B, C, D
~j C 2 n
Configure all MUs within RF range with the room
specified in n
Parameters
Description
v
Room flags (8 bits)
n
77 = Room A
BB = Room B
DD = Room C
EE = Room D
v - Room flags (8 bits)
bit 7
6
5
4
3
2
1
bit 0
reserved
reserved
reserved
reserved
RoomA
RoomB
RoomC
RoomD
bit 7-4 reserved
