39 Conference Control Commands
Parameters
Description
muad
MU ID
[range: 0x1 0xFFFFFF]
m
1 = request for speaking // 0 = stop speaking
tf
Hardware type und MU flags (16 bits)
[range: 0x0 0xFFFF]
tf - Hardware type und MU flags (16 bits)
bit 15
14
13
12
11
10
9
8
N.U.
HWType
7
6
5
4
3
2
1
bit 0
N.U.
MUZone
AllocationMode
bit 15-12 N.U.: not in use, unimplemented bit
bit 11-8 HWType: Hardware type
bit 7 N.U.: not in use, unimplemented bit
bit 6-4 MUZone: MU Zone
>> These zones are used, for example, to sound different locations, which
are then discreetly assigned to the zones. When the zoning function is
enabled, each output is assigned to a specific zone. In each zone,
several microphone units are mixed together according to their division.
For example, a zone can also be assigned to the headphone output of
the microphone units.
0000
Single MU (1 button)
0001
Double MU (2 buttons)
0010
Chairman MU (3 buttons)
0011
Revoluto MU (1 button)
0100
Revoluto MU (2 buttons)
0101
Reserved
0110
Reserved
0111
Reserved
1000
Reserved
1001
Reserved / Test MU
> 1001
Generic MU
000
MU Zone 1
001
MU Zone 2
010
MU Zone 3
011
MU Zone 4
