49 (Advanced) MU List Management
Notes: If first digit is F,
MU is not registered (ghost MU).
If all digits are F, the list position is empty.
n
MU flags, first part (8 bits)
[range: 0x00 0xFF]
m
MU flags, second part (8 bits)
[range: 0x00 0xFF]
s
MU status (8 bits)
[range: 0x00 0xFF]
v
Voting status (8 bits)
n - MU flags, first part (8 bits)
bit 7 reserved
bit 6-4 MUZone: represents the zone in which the MU is used
>> These zones are used, for example, to sound different locations, which
are then discreetly assigned to the zones. When the zoning function is
enabled, each output is assigned to a specific zone. In each zone,
several microphone units are mixed together according to their division.
For example, a zone can also be assigned to the headphone output of
the microphone units.
bit 3-0 AllocationMode
>> The AllocationMode refers to the assignment of MUs to a specific func-
tionality. This functionality is important when assigning audio streams,
since a stream is permanently reserved for a chairman.
bit 7
6
5
4
3
2
1
bit 0
reserved
MUZone
AllocationMode
000
MU Zone 1
001
MU Zone 2
010
MU Zone 3
011
MU Zone 4
0000
Single Delegate (SDel)
0001
Double Delegate
(DDelL, DDelR)
0010
Chairman (Chrm)
0011
reserved
