71 Microphone Mode Commands
v - Mute settings (8 bits)
bit 7
6
5
4
3
2
1
bit 0
N.U.
N.U.
N.U.
N.U.
N.U.
N.U.
MuteMode
GlobalMute
bit 7-2 N.U.: not in use, unimplemented bit
bit 1 MuteMode: Push-to-Mute or Toogle Mute
1 = Push-to-Mute
0 = Toogle Mute
>> This bit position indicates in which mute mode the system is.
Note: To fully set the mute mode, the J A command must also be
executed; its execution is not visible in this bit position.
bit 0 GlobalMute: Mute of all registered resp. active microphones if mute is
pressed on one unit
1 = activated
0 = deactivated
>> This bit position indicates whether global mute is activated or
deactivated.
Communication direction
Controller -> CU
Syntax
Description
E 105
Read byte at register 0x105
E 105 v
Write the value v at register 0x105
Parameters
Description
v
Mute settings
>> including: Mute Mode second command
