Beyerdynamic QUINTA Series - Commands for Mute Status

73 Microphone Mode Commands
7.3 Commands for Mute Status
This command is used to mute or unmute the individual streams resp. channels of the
CU. In addition to setting the mute status, the latter can also be queried; however, this
only happens indirectly each time the mute status changes.
To set and read the mute status of the four microphone channels, the corresponding
DSP register 0x42 is addressed directly.
v - Mute Status values (8 bits)
bit 7
6
5
4
3
2
1
bit 0
N.U.
N.U.
N.U.
N.U.
MuteChan-2
MuteChan-3
MuteChan-4
MuteChan-1
bit 7-4 N.U.: not in use, unimplemented bit
bit 3 MuteChan-2 : Mute channel 2
1 = muted
0 = unmuted
bit 2 MuteChan-3 : Mute channel 3
1 = muted
0 = unmuted
bit 1 MuteChan-4 : Mute channel 4
1 = muted
0 = unmuted
bit 0 MuteChan-1: Mute channel 1
1 = muted
0 = unmuted
>> These bit positions show which of the four channels are muted or open.
Important
Please note the order of the channels in the individual bits!
Communication direction
Controller -> CU
Syntax
Description
P 42 v
Set Mute Status
Parameters
Description
v
Mute Status values
