Instruction Manual
BGS technic KG
Bandwirkerstr. 3
D-42929 Wermelskirchen
Tel.: 02196 720480
Fax.: 02196 7204820
mail@bgs-technic.de
www.bgstechnic.com
© BGS technic KG, Copying and further use not allowed
Art. 5268
Special Twist Sockets
CONTENT
22 mm Twist Socket
1/2“ drive
24 mm Twist Socket
1/2“ drive
27 mm Twist Socket
1/2“ drive
32 mm Twist Socket
1/2“ drive
36 mm Twist Socket
3/4“ drive
41 mm Twist Socket
3/4“ drive
Nut Removing Pin
CHARACTERISTICS
This set of tools was designed to help loosening damaged screws and nuts with right hand threads,
which can’t be loosened with ordinary sockets, anymore.
These sockets are particularly helpful when rusted, deformed or otherwise seriously damaged threads
need to be loosened. This set of tools, with a durability of HRC52-55, applies to AISI4340 standards.
SAFETY ADVICE
Always wear safety goggles to protect yourself from splinters!
These sockets are only suitable for use with hand-operated tools, never use an impact
wrench.
Wear safety gloves, so you minimize the risk of injuries that can be caused by any
splitters or suddenly slipping of sockets.
INSTRUCTION
1. Take a hammer and bang a socket with suitable size on the screw/nut that needs to be loosened.
2. Now, use a suitable ratchet, sliding bar, etc. and turn the special twist socket counter-clockwise to
loosen the damaged screw/nut. Note: These sockets are exclusively suitable for screws/nuts with
right hand thread.
3. After removing the damaged screw/nut, push the removing pin through the socket to remove the
screw/nut from the socket (as shown in picture).
3
Removing the screw/nut out of the special socket
