Biasi MULTIPOINT 14S - Technical Specifications; Technical Data

- 7 -
USE
DESCRIPTION OF UNIT
2 TECHNICAL SPECIFICATIONS
2.1 Technical Data
Model MULTIPOINT 14S MULTIPOINT 16S
Nominal heat input (Hi) kW 28.0 30.0
Minimum heat input (Hi)
G20 kW 9.0 9.5
G30 kW 9.0 9.5
G31 kW 8.0 8.5
Nominal heat output
G20 kW 25.4 27.4
G30 kW 25.4 27.8
G31 kW 25.4 27.8
Minimum heat output
G20 kW 8.2 8.7
G30 kW 8.3 8.9
G31 kW 7.4 7.9
Appliance type C13-33
Gas type 2H-G20-20mbar / 3B-G30-30mbar / 3P-G31-37mbar
Gas category II2H3P / II2H3B/P
Nom. gas supply pressures
G20 Pa-mbar 2000 - 20
G30 Pa-mbar 2900 - 29
G31 Pa-mbar 3700 - 37
Min. gas supply pressures
G20 Pa-mbar 1700 - 17
G30 Pa-mbar 2000 - 20
G31 Pa-mbar 2500 - 25
Max. gas supply pressures
G20 Pa-mbar 2500 - 25
G30 Pa-mbar 3500 - 35
G31 Pa-mbar 4500 - 45
Maximum gas flow rate (Q.nom.)(Hi)
G20 m
3
/h 2.96 3.17
G30 kg/h 2.21 2.37
G31 kg/h 2.18 2.33
Minimum gas flow rate (Q.min.)(Hi)
G20 m
3
/h 0.95 1.01
G30 kg/h 0.71 0.75
G31 kg/h 0.7 0.74
Max. flue gas temperature at 60°/80°C G20 °C 118 118
Min. flue gas temperature at 60°/80°C G20 °C 65 65
Max. flue gas mass flow rate G20 kg/s 0.0215 0.0230
Min. flue gas mass flow rate G20 kg/s 0.0045 0.0050
