BIFFI RPS Series - Page 22

July 2020
Installation, Operation and Maintenance Manual
MAN 573 Rev. 8
Table 7. With jackscrew manual override MSJ or handwheel manual override MHW
Actuator Model WRENCH C1 (mm) Wrench C2 (mm)
RP 14/15-MSJ/MHW 24 41
RP 30-MSJ/MHW 32 50
RP 60-MSJ/MHW 36 55
RP 120-MSJ/MHW 36 60
Figure 15
Figure 14
Actuator Model WRENCH C1 (mm) Wrench C2 (mm)
RP 14/15 17 41
RP 30 17 50
RP 60 17 55
RP 120 17 60
Table 6. Without jackscrew manual override
Operation and Use18
Section 3: Operation and Use
