3. Installation
①When installing, align the bracket with the screw hole, and use the M4*6 hexagon
screw to tighten and fix;
②Put the bracket into the frame tube, confirm the position, and use M4*12 Allen screw
to tighten and fix.
*Instrument damage caused by excessive torque is not covered by the warranty.
