10. Wire definition
Definition of standard cable
Table 1 Standard cable Sequence Table
No.
Color
Function
1
Red
Battery+
2
Blue
Weak lock
3
Black
Battery-
4
Green
UART - RECEIVE
(RXD)
5
Yellow
UART - SEND (TXD)
