Sensorless homing function

As shown, connect the corresponding axes with the jump caps to choose

Sensorless homing function

If you choose this function, you cannot use external ENDSTOP!

NOTE:

5V power supply for BLtouch, TFT, RGB interfaces

1、 To use the onboard 5V PSU, short the pins shown in the above image using a jumper.

2、To use an external BIGTREETECH DCDC5V V1.0 module, short the pins shown in the above

image using a jumper.
