Binks TROPHY AA 4400 - Page 15

TROPHY AA TIP OFFERING
FINE FINISH TIP SIZES OFFERED
PART
NUMBER
ORIFICE
FAN WIDTH
*
CAPACITY
**
REPLACEABLE
SEAL
RS-0909-F
.23mm
[.009in]
250mm [10in]
148 CC
[.039 GPM]
RS-5858-K5
RS-0911-F 300mm [12in]
RS-1109-F
.28mm
[.011in]
200mm [8in]
227 CC
[.060 GPM]
RS-5859-K5
RS-1111-F 250mm [10in]
RS-1113-F 300mm [12in]
RS-1115-F 350mm [14in]
RS-1309-F
.33mm
[.013in]
250mm [10in]
341 CC
[.090 GPM]
RS-5860-K5
RS-1311-F 300mm [12in]
RS-1313-F 350mm [14in]
RS-1315-F 400mm [16in]
RS-1509-F
.38mm
[.015in]
250mm [10in]
454 CC
[.120 GPM]
RS-5861-K5
RS-1511-F 300mm [12in]
RS-1513-F 350mm [14in]
RS-1515-F 400mm [16in]
RS-1517-F 450mm [18in]
RS-1709-F
.43mm
[.017in]
250mm [10in]
606 CC
[.160 GPM]
RS-5862-K5
RS-1711-F 300mm [12in]
RS-1713-F 350mm [14in]
RS-1715-F 400mm [16in]
RS-1717-F 450mm [18in]
* Fan width based on 69 bar [1000 PSI] of water sprayed at 300mm
[12in] from surface. Actual results may vary based on material
sprayed.
** Capacity based on 34 bar [500 PSI] of uid pressure using water
pressure.
TWIST TIP SIZES OFFERED
PART
NUMBER
ORIFICE
FAN WIDTH
***
CAPACITY
****
9-211-75 .28mm [.011in]
100mm
[4in]
454 CC [.120 GPM]
9-213-75 .33mm [.013in] 681 CC [.180 GPM]
9-215-75 .38mm [.015in] 908 CC [.240 GPM]
9-217-75 .43mm [.017in] 1173 CC [.310 GPM]
9-307-75 .18mm [.007in]
150mm
[6in]
189 CC [.050 GPM]
9-309-75 .23mm [.009in] 341 CC [.090 GPM]
9-311-75 .28mm [.011in] 454 CC [.120 GPM]
9-313-75 .33mm [.013in] 681 CC [.180 GPM]
9-315-75 .38mm [.015in] 908 CC [.240 GPM]
9-317-75 .43mm [.017in] 1173 CC [.310 GPM]
9-319-75 .48mm [.019in] 1457 CC [.385 GPM]
9-409-75 .23mm [.009in]
200mm
[8in]
341 CC [.090 GPM]
9-411-75 .28mm [.011in] 454 CC [.120 GPM]
9-413-75 .33mm [.013in] 681 CC [.180 GPM]
9-415-75 .38mm [.015in] 908 CC [.240 GPM]
9-417-75 .43mm [.017in] 1173 CC [.310 GPM]
9-419-75 .48mm [.019in] 1457 CC [.385 GPM]
9-421-75 .53mm [.021in] 1779 CC [.470 GPM]
9-435-75 .89mm [.035n] 4959 CC [1.31 GPM]
9-509-75 .23mm [.009in]
250mm [10in]
341 CC [.090 GPM]
9-511-75 .28mm [.011in] 454 CC [.120 GPM]
9-513-75 .33mm [.013in] 681 CC [.180 GPM]
9-515-75 .38mm [.015in] 908 CC [.240 GPM]
9-517-75 .43mm [.017in] 1173 CC [.310 GPM]
9-519-75 .48mm [.019in] 1457 CC [.385 GPM]
9-521-75 .53mm [.021in] 1779 CC [.470 GPM]
9-523-75 .58mm [.023in] 2158 CC [.57 GPM]
9-525-75 .64mm [.025in] 2536 CC [.670 GPM]
9-611-75 .28mm [.011in]
300mm
[12in]
454 CC [.120 GPM]
9-613-75 .33mm [.013in] 681 CC [.180 GPM]
9-615-75 .38mm [.015in] 908 CC [.240 GPM]
9-617-75 .43mm [.017in] 1173 CC [.310 GPM]
9-619-75 .48mm [.019in] 1457 CC [.385 GPM]
9-621-75 .53mm [.021in] 1779 CC [.470 GPM]
9-623-75 .58mm [.023in] 2158 CC [.57 GPM]
9-625-75 .64mm [.025in] 2536 CC [.670 GPM]
9-627-75 .69mm [.027in] 2801 CC [.740 GPM]
9-631-75 .79mm [.031in] 3899 CC [1.03 GPM]
9-635-75 .89mm [.035n] 4959 CC [1.31 GPM]
9-713-75 .33mm [.013in]
350mm
[14in]
681 CC [.180 GPM]
9-715-75 .38mm [.015in] 908 CC [.240 GPM]
9-717-75 .43mm [.017in] 1173 CC [.310 GPM]
*** Fan width based on 152 bar [2200 PSI] of latex sprayed at
300mm [12in] from surface. Actual results may vary based
on material sprayed.
**** Capacity based on 152 bar [2200 PSI] of uid pressure
using latex.
EN
77-3131-R2 (3/2018) 15 / 16 www.carlisleft.com
