Binks TROPHY AA 4400 - Parts List

PARTS LIST
ITEM
NO.
PART NO. DESCRIPTION
4400-
HF0000
FLAT TIP
QTY.
4400-
H10000
FLAT TIP
QTY.
4400-
H20000
FLAT TIP
QTY.
4400-
LF0000
FLAT TIP
QTY.
4400-
HT0000
TWIST TIP
QTY.
4400-
LT0000
TWIST TIP
QTY.
1 54-6008 AIR VALVE HOUSING 1 1 1 1 1 1
2 54-5935-K5 NEEDLE RETURN SPRING KIT (MULTI-PACK) 1 1 1 1 1 1
3 54-6131-K SPINDLE SEAL & SPRING KIT 1 1 1 1 1 1
3a REAR SEAL 1 1 1 1 1 1
3b AIR VALVE SPRING 1 1 1 1 1 1
3c VALVE SEAL 1 1 1 1 1 1
3d FRONT SEAL 1 1 1 1 1 1
4 54-5815 SPREADER VALVE ASSEMBLY 1 1 1 1 1 1
4a VALVE STEM 1 1 1 1 1 1
4d VALVE BODY 1 1 1 1 1 1
4c SN-71X-K2
l
O-RING (MULTI-PACK) 1 1 1 1 1 1
4b
l
PIN 1 1 1 1 1 1
4e
l
SNAP RING 1 1 1 1 1 1
5 54-5937 AIR VALVE & FLUID NEEDLE ASSEMBLY 1 1 1 1 1 1
6 54-6114 TRIGGER NUT 1 1 1 1 1 1
7 54-6115 TRIGGER SCREW 1 1 1 1 1 1
8
SPA-71-K5
SPA-71-K10
BAFFLE PLATE (MULTI-PACK) 1 1 1 1 1 1
9
54-5799-K FLUID NOZZLE & GASKET (FLAT TIP) 1 1 1 1 – –
54-5832-K FLUID NOZZLE & GASKET (TWIST TIP) – – – – 1 1
9a
SPA-98-K5 GASKET (MULTI-PACK) – – – – – –
SPA-98-K10 GASKET (MULTI-PACK) – – – – – –
10 SEE PAGE 10 REVERSABILE TWIST TIP – – – – – –
11
54-5924-K HVLP TWIST TIP AIR CAP ASSEMBLY – – – – 1 –
54-5925-K LVMP TWIST TIP AIR CAP ASSEMBLY – – – – – 1
12
SEE PAGE 10 FLAT TIP ASSEMBLY – – – – – –
SEE PAGE 10 FINE FINISH FLAT TIP ASSEMBLY – – – – – –
13
54-5878-K 9X-H+ AIR CAP ASSEMBLY (4400-HF0000) 1 – – – – –
54-5890-K AA10 AIR CAP ASSEMBLY (4400-H10000) – 1 – – – –
54-6030-K AA10+ AIR CAP ASSEMBLY (4400-H20000) – – 1 – – –
54-5797-K 9X-L AIR CAP ASSEMBLY (4400-LF0000) – – – 1 – –
14 SN-9-K3 AIR INLET (MULTI-PACK) 1 1 1 1 1 1
15 SLOTTED ROUND HEAD SCREW, 1/4" - 20 x 1/2", S.S. 1 1 1 1 1 1
16 54-6019

TRIGGER 1 1 1 1 1 1
17 54-6015 FLUID TUBE ASSEMBLY 1 1 1 1 1 1
17a FLUID TUBE ADAPTER 1 1 1 1 1 1
17b 54-5896-K5 FLUID TUBE RETAINER (MULTI-PACK) 1 1 1 1 1 1
17c 54-5899 FERRULE NUT 1 1 1 1 1 1
17d 54-6017 FILTER BRACKET 1 1 1 1 1 1
17e 54-1835
p
FLUID FILTER, 100 MESH 1 1 1 1 1 1
17f 54-4726-K DISC FILTER BODY, 1/4" NPS (M) 1 1 1 1 1 1
17g 54-4726-K DISC FILTER RETAINER 1 1 1 1 1 1
18 54-5897 JIC #5 FLUID INLET FITTING (SOLD SEPARATELY) – – – – – –
19 72-2360 SWIVEL ADAPTER, 1/4" NPS M X F (SOLD SEPARATELY) – – – – – –
20 SPN-7 TOOL 1 1 1 1 1 1
Parts are included within the following packing kits:
l Parts are included in kit: GTI-428-K5
ALTERNATE ITEMS (SOLD SEPERATELY):
p 54-1836 FLUID FILTER, 60 MESH
 54-6018 TRIGGER, SHORT PULL
