CONTROL PANEL INSTALLATION
ALWAYS HAVE ALL UTILITY LINES AND EQUIPMENT MARKED BY A LOCATING SERVICE PROVIDER PRIOR TO
PERFORMING ANY WORK.
ALL ELECTRICAL WORK MUST BE PROPERLY PERFORMED BY A QUALIFIED ELECTRICIAN PER ALL APPLICABLE
CODES. FAILURE TO DO SO MAY RESULT IN SEVERE BODILY INJURY OR DEATH.
All FAST® system electrical parts are certified for safety. The control panel enclosures meet NEMA4X standards for all-
weather use (but not explosive or submerged environments).
1. Examine wiring directions for the supplied FAST® control panel. Make sure the facility electrical supply matches
the label on the control panel and is compatible with the blower (voltage, phase, frequency, amperage, etc.).
2. A dedicated breaker is required in the building’s master electrical panel. Make connections between the master
panel and FAST® control panel.
3. Make connections between blower and FAST® control panel per the electrical diagram.
4. BioMicrobics control panels can also be used with optional external inputs and outputs, such as dry contact
input and output for alarm signaling.
5. BioMicrobics manufactures control panels that also power UV systems. The track system (or other auto-dialer)
can also be connected to the panel.
6. For voltage, see label on control panel box.
CONTROL PANEL DETAILS
With every FAST® unit, BioMicrobics provides a control panel that will match the electrical supply selected and the
power requirements of the blower. The table below summarizes the control panel details for the various configuration
options.
Enclosure
Type
Dimensions
Height, Width, Depth
Voltage Phase
Hz
Horsepower
8
x 5 ¼ in [21.6 x 23.8 x 13.3 cm]
8
x 5 ¼ [21.6 x 23.8 x 13.3 cm]
8
x 5 ¼ in [21.6 x 23.8 x 13.3 cm)
8
8
x 6 in [35.9 x 19.7 x 15.2 cm]
8
8
x 6 [35.9 x 19.7 x 15.2 cm]
8
8
x 6 [35.9 x 19.7 x 15.2 cm]
Box-lid 14
1
/
8
x 7
7
/
8
x 6. [35.9 x 19.7 x 15.2 cm] 460 – 480VAC 3 60 ½ - 10 HP
