57
1-5. “TSE” and “TSE eq” Assay Parameter Format
“TSE” and “TSE eq” parameter is same format.
All parameter data is ASCII code data.
Transmit format: <“,”(0x2c)><TSE item 1><“,”><TSE item 2><“,”> …<TSE item 7><“,”>
“,”(0x2c) delimits each parameters item.
“TSE” and “TSE eq” assay data download or upload orders:
Item P.C or Reader Transmit data
1
Report title [24]:
Report title (for internal & external print report)
ASCII characters (max 24characters)
2
Maximum OD value for Control
Negative
“1” to “3500”
This value is Maximum OD * 1000, no decimal point
data length max: 4 characters
3
Minimum O.D value for Control
Negative
“-3500” to “3500”
This value is Minimum OD * 1000, no decimal point
data length max: 5 characters (include sign character)
(This value is lower than Max O.D value for CN.)
This value is not being used.
4
validation data rang for Control
Negative
“1” to “999”
Data range (0.001 to 0.999 * 1000, no decimal point
data length max: 3 characters
5
Minimum O.D value for Control Positive
“1” to “3500”
This value is Minimum OD * 1000, no decimal point
data length max: 4 characters include sign flag
6
Calculation value k1
(Positive Cut-off=(CNx + K1) * k2)
“0” to “9999”
K1 Calculation value * 1000
data length max: 4 characters
7
Calculation value k2
(Positive Cut-off=(CNx + K1) * k2)
“0” to “9999”
K2 Calculation value * 1000
data length max: 4 characters
8
Calculation value k3
(Negative Cut-off= (CNx + K3) * k4)
“0” to “9999”
K3 Calculation value * 1000
data length max: 4 characters
9
Calculation value k4
(Negative Cut-off= (CNx + K3) * k4)
“0” to “9999”
K4 Calculation value * 1000
data length max: 4 characters
Example:
“,TSE assay report ,2500,123,400,1010,210,1000,210,900
