11. Connect the two well counter cables to the well counter fittings. The larger connector (MHV) should
be connected to the high voltage fitting on the well. The smaller connector (BNC) connects to the
well signal fitting. Allow the ends of both cables to lie off to the side.
12. On the underside of the large shelf, directly below the MCA shelf, is a power strip. If your unit has a
cover over the plug sockets (some units do not), use a Phillips screwdriver to remove the three
screws that hold the cover in place. Place the cover aside, retaining the screws.
13. Open the printer box and remove the small box containing the printer power pack. Place the power
pack onto the MCA shelf directly above the power strip, or onto the shelf with the powerstrip.
14. Route the 3-prong power plug from the printer power pack down through one of the MCA shelf
cable holes and plug it into the power strip. Now take the long power pack cable with the
rectangular end, route it along the back of the MCA shelf and down through the left side MCA shelf
cable hole. Continue to route this cable down through the large shelf vertical cover cable hole, down
through the printer shelf vertical cover cable hole and, finally, back up through the printer shelf
cable hole. Allow eight to ten inches of the cable to protrude through the printer shelf cable hole.
15. Take the two well counter cables and route them under the printer shelf, up through the printer shelf
vertical cover cable hole, through the large shelf vertical cover cable hole and, finally, through the
MCA shelf cable hole. Pull the cables snug and allow them to hang out from the front of the MCA
shelf.
16. Locate the printer cable. Run the strip end of this cable through the large shelf side cable hole, down
through the large shelf vertical cover cable hole, down through the printer shelf vertical cover cable
hole, and finally, back up through the printer shelf cable hole. Allow eight to ten inches of the cable
to protrude through the printer shelf cable hole.
17. Reinstall the vertical cable cover using a Phillips screwdriver and the three screws removed in step
#5. Ensure that cables are tucked neatly inside the cover.
18. Remove the printer from the printer box and place it on the printer shelf so that the front faces the same direction
as the large shelf push bar. Connect the printer power pack cable and the printer signal cable to the appropriate
ports on the back of the printer. To make these connections, turn the printer to expose the connection ports.
19. Open the cover on the printer and remove the tape that holds the print carriage from moving. Open
up the print ink cartridge packs and slide them into the print carriage on the printer. The cartridge
should slide in, then snap back into position. Place a stack of paper in the paper tray.
20. Loosen the collimator locking knob and rotate the collimator into a vertical position with the
distance rod facing down. Tighten the locking knob.
21. If you have not already done so, use an adjustable wrench to remove the RED shipping bolts located
near the vertical lock knob. (This bolt keeps the arm from moving during shipment.)
22. If necessary, adjust the uptake arm height. To do this, loosen the vertical column locking knob and
slide the counter-balanced arm to the desired position. Tighten the locking knob to secure the uptake
arm at the desired height.
23. Near the top of the collimator, locate the set screw. Use the supplied 1/32" Allen wrench to loosen
the screw in a counterclockwise direction until it retreats enough to allow passage of the tube
assembly into the collimator.
