biodex BioSway - Connections and Adjustments

The BioSway is quick and easy to assemble. Simply remove the shipping knob and store it in the
handle, connect the components as described on the connection instruction placard, and level
t
he platform as needed. The entire process should take only a few minutes.
Figure 3.1. Figure 3.2.
Figures 3.1 and 3.2. Remove the shipping knob and insert it into the handle for storage. Be sure to replace
the knob if transporting the system.
Figure 3.3. BioSway components shown in the optional hard case.
1. Foam pad
2. Cables
3. AC power adapter
4. Blindfold
5. Connection instruction placard
6. Base unit
7. Display unit (NOTE: Store this upside down in the optional hard case.)
8. Table Top Stand (included)
3. CONNECTIONS AND ADJUSTMENTS
— 3-1 — CONNECTIONS AND ADJUSTMENTS
1
7
2
3
4
6
5
