18. CONNECTION SCHEMES
18.1. SCHEME NR.1: SYSTEM WITH RADIATOR THERMOSTAT VALVES
The room thermostat is not required. System is time leaded by timer (TEN), which is an integral part
of the boiler. Thermostatic valves allow micro temperature control in individual rooms.
Connection scheme 1
