Patient Monitor User’s manual
1-4
1. Equipotentiality terminal
Base on the requirements of safety and anti-interference, the monitor must
be connected with equipotentiality system individual. When connected together,
the various parts of an equipment or of a system will be brought to the same
potential, not necessarily being the earth (ground) potential.
2. AC power input connector
3. VGA display connector
Connect to standard VGA display for secondary displaying.
4. Wired network connector
Standard RJ45 socket. It is used for connection with the central monitoring
system provided by manufacturer.
5. SD Memory card slot
6. USB socket
Connect to USB device, such as mouse.
7. Nurse call connector
Connect to nurse call system in hospital. When an alarm occurs,
outputting the nurse call signal to remind nurse.
8. Auxiliary output / Defibrillator synchronization connector
Connect to the device, such as oscillograph to output analog signals. It
also can be connected to defibrillator for output defibrillator synchronization
signal.
Warning:
Equipment connected to the analog or digital interfaces must comply
with the respective IEC standards (e.g. IEC 60950 for data processing
equipment and IEC 60601-1 for medical equipment). Furthermore all
configurations shall comply with the current version of the standard
for SYSTEMS IEC 60601-1-1. Everybody who connects additional
equipment to the signal input part or signal output part configures a
medical system, and is therefore responsible that the system complies
with current version of the requirements of the system standard IEC
