BionX G2 - Handling and Charging the Battery

12
Inserting the rear rack battery:
1
Openthelockcylinder:pleaseensurethatthekeyisremovedfromthelockcylinder
2
Place the battery onto the battery harness
3
Gently push the battery in a forward direction, towards the battery connector
Make sure the battery is inserted all the way, flush with the battery connector
4
Push in the lock cylinder until a ‘click’ is heard
Removing of the rear rack battery:
1
Turnoffthesystemviatheconsole(noillustration)
2
Turn the key in the lock cylinder until it pops out
3
Remove the key from the lock cylinder
4
Pull the battery backwards, along the battery rail
Handling and Charging the Battery
WARNING
BionX batteries shall only be recharged with BionX chargers or BionX power supplies.
Never short circuit the battery by connecting the contacts of the battery. Never open the
battery. This could damage the battery and possibly lead to overheating or ignition of the
battery. The battery cannot be serviced by the user. Opening the battery case voids all
warranty and product liability claims. Never use a battery which has obvious damage
to the housing or the connector.
001
001
001
001
001
001
001
001
001
001
2
3 4
1” (25.4mm)
001
001
CLICK
WARNING
Do not force the battery onto the battery dock. This can bend the battery connector,
or damage the rear light.
1 2
3
4
