BionX G2 - SL Motor; Brake Switch; Power Supply

7
3
SL Motor
• DCrear,hightorque(HT)hubmotor
• Nom.250W(EU),350W(NA)
• Nom.9Nm/max.40Nm(6.6/30lb-ft)
• 1.2Kg(2.6lb)lighterthanthe250HT(EU)/
350HT(NA)motor
• Brushless, gearless
• Generate mode for energy recuperation
• Integrated torque sensor
4
Brake switch
• A surface mounted reed switch –
connected to the BionX console and magnet
• Uponactivationassistanceisshutoff(“killswitch”)
generate mode is activated
Power Supply
• Powersupplytorechargethe48VLiMnbattery
• Inputvoltage:100-240V
• Outputvoltage:26V
• Max. charge current: 3.45A
• Output:90W
