BionX G2 - 37 V Rear Rack Battery; 250, 250 HT (EU); 350 HT (NA), or 500* Watt Motor; Brake Switch; 37 V Single Light Battery Charger

9
1
2
3
4
2b
37V Rear Rack Battery
• LithiumManganese(LiMn)
• Removable, lockable
• Fully charged in: 4-5h
• RRL-37V/9.6Ah/355Wh
• RRM-37V/6.4Ah/236Wh
3
250, 250HT (EU) / 350HT (NA),
or 500* watt Motor
• DC rear hub motor
• 250W:nom.7Nm/max.25Nm(5/18.5lb-ft)
• 250HT(EU)/350HT(NA):
nom.9Nm/max.40Nm(6.6/30lb-ft)
• 500W:nom.9Nm/max.25Nm(6.6/18lb-ft)
• Brushless, gearless
• Generate mode for energy recuperation
• Integrated torque sensor
4
Brake switch
• A surface mounted reed switch – connected to the
BionX console and magnet
• Uponactivationassistanceisshutoff(“killswitch”)
generate mode is activated
37V Single Light Battery Charger
(PL systems 2012 to present)
• Torechargethe37VLiMn-battery
• Inputvoltage:100-240V
• Outputvoltage:37V
• Max. charge current: 2A
22.2V, 26V or 37V Two Light Battery Charger
(PL systems 2011 and earlier)
• Torechargethe22.2V,26Vor37VLiMn-battery
• Inputvoltage:switchablebetween115-230V
• Outputvoltage:22.2V,26Vor37Vdepending
on model
• Max. charge current: 2A
*Note:the500wattmotorisnotlegalinallcountries.CheckwithyourlocalBionXdealerforlocallegislationand/oravaliability
