concerns, and therefore, parents should not rely solely on temperature
readings to evaluate the status of your child’s health. If you have any
concerns, consult with your doctor.
2. PRODUCT DIAGRAM
Ear Probe
Forehead Probe
Scan Button
ON / MEM Button
Protective Probe Cover
LCD Display
FIGURE 1
Battery Cover Pinhole
Battery Cover
Ear Probe
Forehead ProbeProtective Probe Cover
