22 | Chapter 2: Hardware installaon
2.8 LEDs
Debug LED: Debug LED Indicators
This LEDs indicate the status of the motherboard.
DRAM - indicates DRAM is not detected or fail.
CPU - indicates CPU is not detected or fail.
VGA - indicates GPU is not detected or fail.
BOOT - indicates boong device is not detected
or fail.
Note
»
»
Aer starng the computer, the LED indicators will light up in the following order:
DRAM → CPU → VGA → BOOT
»
»
When the computer is ready, the LED indicator will show where the error occurred and will stay on
unl the problem is solved.
»
»
Aer the computer is started, the Debug LED will not light up if there is no abnormality detected.
LEDs
Below LEDs are controlled by RACING GT EVO program. Please refer to Chapter 3.3 for more
detail soware seng.
●
RGB LED Header(5V/12V)
