User’s Manual
44
CAS# Latency (tCL)
This item allows you to select CAS Latency of DDR3.
Options: 9 (Default) / 3 ~ 15
RAS# to CAS# Delay (tRCD)
This item allows you to select Row Address to Column Address Delay of DDR3.
Options: 9 (Default) / 3 ~ 15
Row Precharge Time (tRP)
This item allows you to select Row Precharge Time of DDR3.
Options: 9 (Default) / 3 ~ 15
RAS# Active Time (tRAS)
This item allows you to select Row Active Time of DDR3.
Options: 24 (Default) / 9 ~ 63
Write Recovery Time (tWR)
This item allows you to select Internal Write to Read Command Delay of DDR3.
Options: 10 (Default) / 3 ~ 31
Row Refresh Cycle Time (tRFC)
This item allows you to select Minimum Refresh Recovery Time of DDR3.
Options: 107 (Default) / 15 ~ 255
Active to Active Delay (tRRD)
This item allows you to select Row Active to Row Active Delay of DDR3.
Options: 4 (Default) / 4 ~ 15
Write to Read Delay (tWTR)
This item allows you to select Internal Write to Read Command Delay of DDR3.
Options: 5 (Default) / 3 ~ 31
Read CAS# Precharge (tRTP)
This item allows you to select Read to Precharge Delay of DDR3.
Options: 5 (Default) / 4 ~ 15
Four Active Window Delay (tFAW)
This item allows you to select Four Active Window Delay of DDR3.
Options: 20 (Default) / 4 ~ 63
