1.3 MAINBOARD SPECIFICATION
Specification
CPU
Support Intel Ivy Bridge CPU
(Co-lay support Sandy Bridge CPU/Embedded CPU SKU)
Intel® Core™ i7-2600 3.4GHz up to 95W
Intel® Core™ i5-2400 3.1GHz up to 95W
Intel® Core™ i3-2120 3.3HHz up to 65W
Chipset INTEL B75 chipset (co-lay with Q77)
BIOS AMI 8M BIOS
Graphic
Intel® Integrated Graphic
Display Memory: Max. shared system memory up to 1759MB
Resolution: VGA: Max. Up to 2048 x 1536 at 75Hz
DVI-D: Max. upto 1920 x 1200 at 60Hz
Main Memory
4x 240pin DDR3 SDRAM max up to 32GB
Each DIMM supports 512MB/ 1GB/2GB/4GB/8GB DDR3
Dual Channel Mode DDR3 memory module
Supports DDR3 1066/1333, DDR3 1600 (Depending on CPU)
Registered DIMM and ECC DIMM is not supported
SATA
Chipset built-in Serial ATA controller
Data transfer rates up to 3.0/6.0 Gb/s
SATA Version 2.0/3.0 specification compliant
RAID 0,1,5,10, SRT support (Supported by Q77 only)
LAN 1x Realtek RTL8111F for PCIe Gigabit LAN
Sound Codec
Realtek ALC892
5.1 channels audio out, High-Definition Audio support
LPC I/O ITE IT8728
Serial Port ST75185CTR x2
Expansion Slots
PCI x2
PCIe x1 x1
PCIe x16 x1
On Board Connectors
& Headers
2*5 pins, 2.54 pitch front panel header x1
2*5 pins, 2.54 pitch front audio for (Line-out & Mic-in) x1
2*13 pins, 2.0 pitch Parallel port pin header x1
SATA connector support 3.0Gb/s x5
SATA connector support 6.0Gb/s x1
2*10 pins, 2.0 pitch, 2 x USB 3.0 ports box-header x1
2*5 pins, 2.54 pitch, 2 x USB 2.0 ports box-header x2
1*4 pins, CPU PWM-FAN header x1
1*3 pins, System DC-FAN header x1
24 pins, ATX power connector x1
4 pins, 12V power connector x1
Buzzer x1
Back Panel I/O
PS/2 KB/MS (for PS/2 keyboard & mouse) x1
VGA x1
DVI-D x1
COM Port x2
