1.4 Rear Panel Connectors
H310MHC2
H310MDC2
Note
»
 HDMI/DVI-D/VGAportsonlyworkwithanIntel®integratedGraphicsProcessor.

»
Maximumresoluon
HDMI:4096x2160@24Hz,compliantwithHDMI1.4
VGA:1920x1200@60Hz
DVI-D:1920x1200@60Hz

»
WhenusingthefrontHDaudiojackandplugintheheadset/microphone,therearsoundwillbe
automacallyDisabled.

»
Themainboardsupportstwoonboarddisplayoutputsatsamemeandthedisplayoutput
conguraoncanbeselectedinIntelgraphicsdriverulity.

»
Tocongure7.1-channelaudio,youhavetouseachassiswithHDfrontpanelaudiomoduleand
enablethemul-channelaudiofeaturethroughO.S.AudioUlity.
The 2/ 4/ 5.1/ 7.1-channel conguraon
Audio Port 2-channel 4-channel 5.1 channel 7.1 channel
Blue (Rear Panel) Line In Line In Line In Side Speaker Out
Green (Rear Panel) Line Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink (Rear Panel) Mic In Mic In Center/Subwoofer Out Center/Subwoofer Out
Green (Front Panel) Headphone Rear Speaker Out Rear Speaker Out Rear Speaker Out
