20 | 第二章: 硬體安裝
2�8 LED燈
Debug LED: 檢測LED指示燈
LED指示燈顯示主板的檢測狀態。
CPU - 表示CPU未檢測到或發生故障。
DRAM - 表示DRAM未檢測到或發生故障。
VGA - 表示GPU未檢測到或發生故障。
BOOT - 表示啟動設備未檢測到或發生故
障。
»
啟動電腦後LED指示燈將按以下順序點亮
CPU→DRAM→VGA→BOOT
»
當電腦準備就緒時LED指示燈將顯示錯誤發生的位置並持續亮著直到問題解決
»
啟動電腦後如果未檢測到異常則Debug LED將不會點亮
