H61MGV3 / H61MLV3 UEFI BIOS Manual
21
4 Boot Menu
This menu allows you to setup the system boot options.
Setup Prompt Timeout
This item sets number of seconds to wait for setup activation key.
Options: 2 (Default)
Bootup NumLock State
This item selects the keyboard NumLock state.
Options: On (Default) / Off
Full Screen Logo Display
This item allows you to enable/disable Full Screen Logo Show function.
Options: Enabled (Default) / Disabled
GateA20 Active
Upon Request – GA20 can be disabled using BIOS services. Always – do
not allow disabling GA20; this option is useful when any RT code is executed
above 1MB
Options: Upon Request (Default) / Always
Option ROM Messages
This item sets the display mode for Option ROM.
Options: Force BIOS (Default) / Keep Current

Biostar H61MGV3 Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
CPU Socket	LGA 1155
Memory Slots	2 x DDR3 DIMM
Max Memory	16 GB
Memory Speed	DDR3 1600/1333/1066 MHz
PCIe Slots	1 x PCIe 3.0 x16, 1 x PCIe 2.0 x1
SATA Ports	4 x SATA 3Gb/s
Audio	Realtek ALC662 6-Channel HD Audio
LAN	Realtek RTL8111E Gigabit LAN
CPU Support	Intel Core i7/i5/i3/Pentium/Celeron
Rear I/O	4 x USB 2.0
Video Outputs	1 x VGA
Power Connector	24-pin ATX + 4-pin ATX 12V
USB Ports	8 x USB 2.0 (4 on rear panel, 4 via internal headers)
