Biostar H61MGV3 User Manual

H61MGV3 / H61MLV3 UEFI BIOS Manual
2
Supported CPUs
This AMI UEFI BIOS supports the Intel
CPU.
Using Setup
When starting up the computer, press <Del>
during the Power-On Self-Test (POST) to
enter the UEFI BIOS setup utility.
In the UEFI BIOS setup utility, you will see
General Help description at the top right
corner, and this is providing a brief
description of the selected item. Navigation
Keys for that particular menu are at the
bottom right corner, and you can use these
keys to select item and change the settings.
Notice
 The default UEFI BIOS settings apply for most conditions to ensure
optimum performance of the motherboard. If the system becomes
unstable after changing any settings, please load the default settings to
ensure system’s compatibility and stability. Use Load Setup Default
under the Exit Menu.
 For better system performance, the UEFI BIOS firmware is being
continuously updated. The UEFI BIOS information described in this
manual is for your reference only. The actual UEFI BIOS information
and settings on board may be slightly different from this manual.
 The content of this manual is subject to be changed without notice. We
will not be responsible for any mistakes found in this user’s manual and
any system damage that may be caused by wrong-settings.

Biostar H61MGV3 Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
CPU Socket	LGA 1155
Memory Slots	2 x DDR3 DIMM
Max Memory	16 GB
Memory Speed	DDR3 1600/1333/1066 MHz
PCIe Slots	1 x PCIe 3.0 x16, 1 x PCIe 2.0 x1
SATA Ports	4 x SATA 3Gb/s
Audio	Realtek ALC662 6-Channel HD Audio
LAN	Realtek RTL8111E Gigabit LAN
CPU Support	Intel Core i7/i5/i3/Pentium/Celeron
Rear I/O	4 x USB 2.0
Video Outputs	1 x VGA
Power Connector	24-pin ATX + 4-pin ATX 12V
USB Ports	8 x USB 2.0 (4 on rear panel, 4 via internal headers)
