Biostar H61MGV3 User Manual

H61MGV3 / H61MLV3 UEFI BIOS Manual
7
Wake system with Fixed Time
This item enables or disables the system to wake on by alarm event. When
this item is enabled, the system will wake on the hr::min::sec specified.
Options: Disabled (Default) / Enabled
Wake up date
You can choose which date the system will boot up.
Wake up hour / Wake up minute / Wake up second
You can choose the system boot up time, input hour, minute and
second to specify.
CPU Configuration
Hyper-threading
Hyper Threading Technology can improve performance by splitting
instructions into multiple streams. This item is enabled for Windows XP and
Linux (OS optimized for Hyper-Threading Technology) and disabled for other
OS (OS not optimized for Threading Technology). When this item is disabled,
only one thread per enabled core is enabled.
Options: Enabled (Default) / Disabled
Active Processor Cores
This item sets number of cores to enable in each processor package.
Options: All (Default) / 1 / 2 / 3

Biostar H61MGV3 Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
CPU Socket	LGA 1155
Memory Slots	2 x DDR3 DIMM
Max Memory	16 GB
Memory Speed	DDR3 1600/1333/1066 MHz
PCIe Slots	1 x PCIe 3.0 x16, 1 x PCIe 2.0 x1
SATA Ports	4 x SATA 3Gb/s
Audio	Realtek ALC662 6-Channel HD Audio
LAN	Realtek RTL8111E Gigabit LAN
CPU Support	Intel Core i7/i5/i3/Pentium/Celeron
Rear I/O	4 x USB 2.0
Video Outputs	1 x VGA
Power Connector	24-pin ATX + 4-pin ATX 12V
USB Ports	8 x USB 2.0 (4 on rear panel, 4 via internal headers)
